High Efficiency Flute Laminator Machine With Min Sheet Size 360mm*360mm

Name: High Efficiency Flute Laminator Machine With Min Sheet Size 360mm360mm
Brand: xinglong
Price: 1 USD

China High Efficiency Flute Laminator Machine With Min Sheet Size 360mm*360mm wholesale

Brand Name : xinglong

Model Number : XL-TM

Certification : CE，BV

Place of Origin : China

MOQ : 1set

Price : Negotation

Payment Terms : L/C, D/A, D/P, Western Union, T/T, MoneyGram

Supply Ability : 5set/month

Delivery Time : 20-30days

Packaging Details : film

Driven type : Electric

Voltage : 380V/50HZ

Economic speed : 0-80 piece/min

Warranty : 1 Year

After-sales service provided : Engineers available to service machinery overseas,Online support,Video technical support,commissioning and training

Total power : 6-6.5KW

Contact Now

Vacuum Servo Corrugated Semi - Automatic Flute Laminator Machine

Characteristics:

This machine can feeding single-side corrugated cardboard automatically, manual feeding Surface.
Surface paper can be adjusted forward and backward and base paper never lead.
This machine adopts double frequency motor with VFD, PLC set machine progress and control glue amount.

With alarm device

Technology Parameters:

Model	BZJ-1300B	BZJ-1500B	BZJ-1600B
Max sheet size	1300mm*1100mm	1500mm*1250mm	1600mm*1250mm
Min sheet size	360mm*360mm	360mm*360mm	360mm*360mm
Mechanical speed	0-80pcs/min	0-80pcs/min	0-80pcs/min
Precision	+-1	+-1	+-1
Weight	about 3000kg	about 3500kg	about 6500kg
Total power	6kw	6.5kw	6.5kw
Surface paper(card paper)	≥200g/m2	≥200g/m2	≥200g/m2
Base paper(card paper)	≥250g/m2	≥250g/m2	≥250g/m2
